Datos del producto:
Pago y Envío Términos:
|
1. Excellent design
2. Light weight,
3. Easy usage
4. Convenient repair
5. Small volume, smart structure
Usage:
With cast iron material: Water, kerosene, light oil, heavy oil, machine oil etc.
With brass gear: Brine, weak acid and chemistry liquid.
| MODEL | MATERIAL | DIAMETER | SPEED (r/min) |
CAPACITY (L/min) |
PRESSURE (MPa) |
NPSH (m) |
POWER (KW) |
WEIGHT (kg) |
| BPC-13 BPB-13 |
BPC: BPB: |
13mm (1/2") |
400 | 21 | 0.3 | 3 | 0.25 | 4.3 |
| BPC-20 BPB-20 |
20mm (3/4") |
400 | 37 | 0.3 | 3 | 0.55 | 7.1 | |
| BPC-25 BPB-25 |
25mm (1") |
400 | 55 | 0.3 | 3 | 0.75 | 11.0 | |
| BPC-35 BPB-35 |
35mm | 400 | 121 | 0.3 | 3 | 1.5 | 21.0 | |
| BPC-50 BPB-50 |
50mm | 400 | 242 | 0.3 | 3 | 3 | 42.0 | |
| BPC-80 BPB-80 |
80mm | 400 | 455 | 0.3 | 3 | 5.5 | 77.2 |
